Sony HXR-NX80 4K NXCAM with HDR & Fast Hybrid AF

The HXR-NX80 4K NXCAM camcorder from Sony offers phase-detection Autofocus (AF) and HDR capabilities in a compact, palm-style body. Suitable for corporate events, broadcast news, and television production, the HXR-NX80 camcorder features a stacked 1" Exmor RS CMOS sensor with 14.2MP, a 12x Zeiss optical zoom, an OLED viewfinder, and 3.5" touchscreen LCD monitor. This camcorder records 4K in XAVC S 4K, streams via 2.4/5 GHz frequency bands, and includes S-Log3/S-Gamut3 functions for additional image control.
  • Single 1" Exmor RS CMOS Sensor
  • XAVC S 4K (3840 x 2160) at 100 Mb/s
  • 4K HDR with Hybrid Log-Gamma (HLG)
  • Zeiss 12x Optical / 18x Clear Image Zoom
Product Code: NX80
Brand: Sony
Availability: Out of Stock
Rs. 305,000

The HXR-NX80 offers professional quality 4K with advanced features such as high-speed auto focus, Instant HDR workflow, up to 960fps* super slow motion and streaming at 2.4GHz.

*960fps (NTSC). 1000fps (PAL).

Amazingly fast precision auto focus

The HXR-NX80 incorporates an advanced Fast Hybrid AF system, alongside face detection and lock-on auto focus technology, making it easy to focus and track a subject while filming.











Volume 90%



First NXCAM professional palm camcorder with 4K HDR

The HXR-NX80 is the first professional palm-sized camcorder to deliver stunning 4K High Dynamic Range (HDR) content with Hybrid Log-Gamma (HLG) file-based workflows. S-Log3 is also supported, enabling you to create beautiful imagery with a wide colour gamut and colour range.

3840 x 2160 pixels. Connect this product to HDR (HLG) compatible Sony TV via a USB cable when displaying 4K HDR movies.

Super slow motion up to 960fps* and S&Q motion up to 120fps**

High Frame Rate shots can turn everyday actions into slow motion ballet. The HXR-NX80 delivers a stunning 120 frames per second (fps) in Full HD XAVC S 10-bit 4:2:0, giving you continuous five-times slow motion expression. Higher frame rates up to 960fps using S&Q motion cache recording are also possible for even greater creative flexibility.

*960fps (NTSC). 1000fps (PAL).

**120fps (NTSC). 100fps (PAL).

Versatile connections for professional workflows

The camcorder features a Multi-Interface (MI) Shoe, HDMI and remote interface to connect with and control remotely a wide variety of compatible Sony accessories, including creating a simple live solution when connected to the optional MCX-500 Multi Camera Live Producer and RM-30BP Remote Commander.

Revolutionary imaging performance with Exmor RS

To deliver imaging performance previously impossible for a compact camcorder. A large 14.2-megapixel (effective) 1.0-type stacked CMOS image sensor delivers beautiful background bokeh defocus effects and superior sensitivity for capturing high-quality images with less noise, even under dark or bright conditions. This sensor integrates up to 273 phase-detection AF points that densely cover approx. 84% of the image area, for precise tracking of subjects throughout the shooting frame.

The sensor also gives you low noise and less blur because more light reaches the sensor, offering clear and steady pictures even in a dark scene with minimum illumination 1.7 lux*.

*LOW LUX mode.











Volume 90%



Enhanced Fast Hybrid auto focus captures action

Enhanced Fast Hybrid auto focus (AF) comprises a number of features: phase-detection AF with up to 273 reference points covering approximately 84% of the image area, face detection and lock-on auto focus technology to estimate subject movement. They all work together seamlessly to capture fast-moving subjects with amazing sharpness.

Instant HDR workflows

Shoot, edit and view HDR content in HLG without the need for additional colour grading.

As the expanding need for HDR content continues, internet video platforms and professionals producing corporate or event content are paying more attention to the added value of HDR. They need to deliver content quickly, without compromising on imaging expression and quality of content. To meet this demand, the HXR-NX80 offers Hybrid Log-Gamma (HLG) recording, in addition to S-Log3, for easy file-based workflows, while achieving the image quality of HDR. This simple workflow enables the shooting, editing and viewing of HDR content in HLG, without devoting a lot of time to post-production work and additional colour grading.











Volume 90%












Volume 90%



Stunning slow motion in Full HD

High Frame Rate shots can turn everyday actions into slow motion ballet. The HXR-NX80 delivers up to 120 frames* per second (fps) in Full HD, giving you a maximum of five-times slow motion expression. There’s no sacrifice in bit depth and no ‘windowing’ of the sensor. So there’s no crop factor, no loss in angle of view. Higher frame rates of 240, 480 and 960fps are also possible at specific resolutions.

*120fps (NTSC). 100fps (PAL).

Professional quality 4K (QFHD) and HD

The HXR-NX80 allows you to record a wide range of 4K (QFHD) and HD formats for maximum flexibility from this stunning palm-sized camcorder. The NX80 supports XAVC S 4K 100/60 Mbps recordings at 30p/25p/24p, XAVC S and AVCHD.











Volume 90%



Networked for high mobility

The HXR-NX80 comes with 2.4GHz Wi-Fi as standard – simply turn on and log onto your preferred network to enable a host of advanced wireless production features:

  • Ustream® direct streaming allows you to share scenes as they happen with high quality picture and sound without a switcher.
  • Wi-Fi/NFC (Near Field Communication) with Content Browser Mobile™ allows the HXR-NX80 to be remotely controlled from a smartphone or tablet computer (iOS 9.0 – 10.3 or Android 4.4 through 7.1) via a Wi-Fi connection. One-touch authentication is also possible with smartphones that offer NFC connectivity

The Content Browser Mobile™ application can be downloaded from the Google Play Store or App Store. Wi-Fi operation cannot be guaranteed with all smartphones and tablet computers.

Wide-angle zoom lens with great control

The HXR-NX80 is supplied with a fixed 29mm wide-angle ZEISS Vario-Sonnar T lens, ideal for capturing panoramic landscapes. The 12x optical zoom can be increased to 18x with Clear Image Zoom, maintaining 4K resolution using Super Resolution Technology or 24x in HD. In addition, the digital extender can double this range again, up to 48x zoom.

The camcorder’s lens ring enables smooth, natural adjustment of focussing or zooming, depending on which mode is selected; while the manual dial and buttons on the side of the body allow swift and easy adjustment of IRIS (aperture), ISO/GAIN and shutter speed.



Optical Zoom



Clear Image Zoom (QFHD)



Clear Image Zoom (HD)



Superb quality monitoring with enhanced OLED viewfinder

You have superb monitoring options with the NX80: an enhanced 0.39-type 2359K dot OLED viewfinder and 3.5-type 1550K dot LCD. The super high resolution OLED viewfinder offers excellent quality brightness, contrast and response, giving you better precision of manual focus operations and eliminating any colour-breaking phenomenon. The LCD gives you further flexible composition options.

Dual XLR inputs

The NX80 has two XLR connecters – so even if you remove the handle with its standard, easy-access XLR connector then a second on the body is still available, making it ideal for applications such as shooting in a confined space, such as a car interior, or when mounting on a gimbal.

Remote operation

The HXR-NX80 has a featured remote interface (2.5 mm stereo mini-mini jack) wired interface. Using a wired remote controller such as the RM-1BP or RM-30BP the focus, zoom, rec start/stop and rec review can be controlled remotely. The camcorder can connect to the optional RM-30BP and MCX-500 Multi Camera Live Producer to form a simple live solution.

Dual media slots

To extend recording time and workflow flexibility, the HXR-NX80 is equipped with two memory card slots and is compatible with SDXC and SDHC cards as well as Memory Stick PRO Duo (Mark 2) / PRO-HG Duo*.

Relay mode automatically switches recording from the first to the second memory card when the first is full; Simul mode allows simultaneous recording to two memory cards (for example to create an immediate back-up version). The HXR-NX80’s two Start/Stop buttons on the handle grip and camcorder body can independently start and stop recording on different memory cards while recording in Simul mode.

*Memory Card Slot 1 only.

Multi-Interface (MI) Shoe

The HXR-NX80 takes advantage of Sony’s flexible Multi-Interface (MI) Shoe, which provides power, signal connections and coordinated on/off switching to compatible Sony accessories. For example, you can connect and control Sony UWP-D wireless microphone systems (sold separately). Please note to use the MI-Shoe the XLR handle must be removed.

Superb quality monitoring with enhanced OLED viewfinder

You have superb monitoring options with the NX80: an enhanced 0.39-type 2359K dot OLED viewfinder and 3.5-type 1550K dot LCD. The super high resolution OLED viewfinder offers excellent quality brightness, contrast and response, giving you better precision of manual focus operations and eliminating any colour-breaking phenomenon. The LCD gives you further flexible composition options.

Simple live solution

The HXR-NX80 is designed to work seamlessly with Sony’s MCX-500 Multi Camera Live Producer, a robust and cost-effective switcher that makes it easy for one person to run a multi-camera live event shoot. When used with the MCX-500 and Remote Commander RM-30BP, a tally indicator will automatically appear on each HXR-NX80’s LCD panel and viewfinder – a red icon indicates when the shot is live (PGM) while green indicates preview mode (PVW). The MCX-500 supports up to nine video inputs, five channel stereo inputs, five channel stereo inputs including XLR with both internal recording and live streaming via Ustream™, Facebook Live, and Youtube Live*.

*Facebook Live and YouTube Live available with V2.0 firmware.

Easily synchronise multiple camcorders

When shooting with multiple camcorders, you can synchronise the timecode of each camcorder using Content Browser Mobile™ (CBM) smartphone application* with optional CBKZ-WTCL upgrade. With this feature, all camcorders can synchronise to the primary camcorder you select or to a manually set time – whichever you prefer.

*Version 3.0 Content Browser Mobile™ required. Compatible with iOS 9.0 through to 10.3, or Android 4.4 through to 7.1.


Specifications of Sony HXR-NX80 4K NXCAM with HDR & Fast Hybrid AF

General Specification
Sensor Type 1-Chip 1" CMOS Sensor
Sensor Resolution 14.2 MP
Screen Resolution 1,560,000 Dots
